PD Trigger Voltmeter Ammeter Current Voltage USB Tester QC3.0 QC2.0 PD3.0 2.0 PPS Fast Charging Protocol Capacity Test ,Easy to Operate

<p>Specifications:</p><p>Monitoring voltage: 4~24V</p><p>Monitor voltage resolution: 0.00001V</p><p>Monitoring voltage accuracy: ±(0.2+2)</p><p>Monitoring current: 0~6.5A</p><p>Display current resolution: 0.00001A</p><p>Monitoring current accuracy: ±(0.5+2)</p><p>Display power: 0~130W</p><p>Display current resolution: 0.00001W</p><p>Monitoring current accuracy: ±(0.5+2)</p><p>Load equivalent resistance: 0~9999.9</p><p>Load equivalent resistance resolution: 0.0001</p><p>Load equivalent resistance accuracy: ±(0.5+2)</p><p>Capacity: 0~9999.99Ah</p><p>Use energy: 0~9999.99Wh</p><p>Cable resistance: 0~9999.9</p><p>D+/D- voltage: 0~3.3V</p><p>D+/D- voltage resolution: 0.001V</p><p>D+/D- voltage accuracy: ±(1.0%+2)</p><p>Equipment temperature: /</p><p>Package size: 50*25*8mm / 1.97* 0.98 * 0.31in</p><p>Package weight: 47g / 1.66oz</p><p>Product selling point:</p><p>1: Compact and portable Type-C multi-function tester: smaller than 2 fingers, easy to carry</p><p>2: Intelligent, diversified functions, portable Type-C multi-function tester</p><p>3: Structure.Three interfaces and three buttons</p><p>Has dual Type-C interfaces, which directly saves a test line, and the test cost and performance are significantly improved. It supports 6.5A high current test and stable operation for a long time!</p><p>4: Comprehensive functions meet all your needs</p><p>All mainstream protocol detection &amp; triggeringwaveform curveline resistance measurementlow internal resistancedrivefree PC upgrade etc</p><p>5: Real-time charging voltage, current and power detection multi-interface display, multi-data measurement</p><p>Use external 16-bit ADC, PD protocol physical chip, test all kinds of USB-C interface chargers, power banks, data cables, mobile phones and laptops and other digital devices</p><p></p><p>trigger voltmeter ammeter,charging test usb c pps,trigger usb tester,usb tester pd trigger,usb current tester pd</p><p>Related Products:usb tester,usb power meter,usb cable tester,usb voltage meter,power meter,usb c tester,voltage meter,voltmeter,battery monitor,usb digital tester,usb meter</p>

• 1: Small, portable Type-C multi-functi on tester
• 2: Intelligent, diversified functions
• 3: Structure.Three interfaces, three buttons
• 4: Real-time charging voltage, current and power detection multi-interface display, multi-data measurement
• 5: Automatic detection/triggering of multiple fast charging protocols
